Please use your smartphone browser to scan the following QR code or search for "CREABEST" in Google Play (Android) / App Store (IOS) to download
After the installation is complete, click to enter the application. Note: The phone’s Bluetooth is always on, and authorization to access the location is allowed.
Click Login/Register and enter the registered email address and password.
Select the appropriate battery model, and then click the battery model to enter the data display interface.
Enter the data view interface to view battery-related data.
Our LiFePO4 battery pack is inner BMS (battery manag-ement system) control. Thus, if the battery works over specified, BMS will stop the battery pack working. Whatever over-charge or over-discharge, over temperature or over voltage, BMS will cut it off. The battery will not work any longer.
Improvement in safety
Light weight
Excellent performances at high temperature
Much long cycle life
Higher energy density than Lead-Acid
No memory effect,More environmental
| Voltage | 12.8V | Cell Type | LiFePO4 |
| Capacity | 120Ah | Discharge Temperature | -20°C -60°C |
| Total Energy | 1535Wh | Charge Temperature | 0°C -55°C |
| Standard discharge current | 150A | Storage Temperature | -20°C -60°C |
| Max discharge current | 200A | Terminal Type | M8 |
| Standard Charge Curren | 30A-60A | Communication | RS232 |
| Recommended charge Voltage | 14.4V-14.6V | Communication Terminal | Not open |
| BMS low voltage protection | 10.8V | Net Weight | 20KG |
| Series/Parallel | 4S1P | Dimensions | 356x169x20mm |
| Resistance | ≤10mΩ | Inverter | 12V 2000W |
1). Charge faster. Support high power charger charging. Battery Accessories include LiFePO4 dedicated charger 30A, additional purchase required.
2). Wide range of applications: campers, caravans, camping, boat, outdoor lighting, outdoor tools, car start temporarily, Off-grid, and so on.
3). You can check the battery status of LiFePO4 on your mobile phone. Accurately measure battery power.
* The LiFePO4 battery did not give rise to burning or exploding when being punctured in the nail penetration test.
* Its Cold Cranking Amps and voltage were all performing normal, even in the low temperature test.
* The great stability in high temperature was remarkable.
* Equiped with first-rate BMS, the battery went well in the short-circuit test, discharge test and the charge test as well.
